V375B12C300BL高壓輸入DC-DC電壓模塊
V375B12C300BL高壓輸入DC-DC電壓模塊
關鍵性規格

輸人電壓值：250 – 425V打印輸出直流電壓：2-48V的輸出熱效率：300W 尺碼規格： 2.28*2.2*0.5in 半磚


*代替設備CINCON企業 CHB300-300S12購貨6-8周


品牌：VICOR

商品情況解紹



Part NumberInput VoltageOutput VoltageOutput CurrentNo load Input CurrentEfficiency (%)I/O Isolation Voltage
CHB300-300S05180~425V5V60A10mA893000VAC
CHB300-300S12180~425V12V25A10mA883000VAC
CHB300-300S24180~425V24V12.5A10mA903000VAC
CHB300-300S28180~425V28V10.7A10mA903000VAC
CHB300-300S48180~425V48V6.25A10mA903000VAC
CHB300-300S05N180~425V5V60A10mA893000VAC
CHB300-300S12N180~425V12V25A10mA883000VAC
CHB300-300S24N180~425V24V12.5A10mA903000VAC
CHB300-300S28N180~425V28V10.7A10mA903000VAC
CHB300-300S48N180~425V48V6.25A10mA903000VAC
時CINCON 還出示600W 、750W的DC-DC壓力填寫電原包塊新產品，CFB600-300S    CFB750-300S一系列。
